Danfoss inverter VLT2800

Supply voltage and power range:

A third * 200-240 - V... 0. 37kW -- 3.7kw

3 * 380-480 - V... 0.55 kW, 18.5 kW


Features and benefits:

• unique cold plate cooling technology allows the inverter to be installed in any direction without the need to reserve transverse cooling space.

• enhanced circuit board coating is used to force ventilation and heat dissipation, which greatly improves the reliability of frequency conversion operation in harsh environment.

• built-in PID controller for optimal closed-loop control.

• built-in RS485 serial communication interface, support MODBUS communication protocol, Profibus and DeviceNet.

• the RFI filter enables the inverter to meet the requirements of the industrial environment specified by the EMC standard without the need to add additional space and safety components.

• built-in dual dc reactor to reduce harmonic interference.

• use the "shortcut menu" setting to start the converter.

• motor self-adaption ensures perfect adaption between inverter and motor.


Application industry:

Pumps, fans, conveyors, extruders, packaging machines, winding machines, cup spinning machines.
